Legacy Audio Signature XD Floorstanding Speakers (Exotic Finishes)

Description

SOLD AS A PAIR – CHOOSE FROM THE EXOTIC FINISHES

MASTERS COLLECTION

Signature XD

The newly released Signature XD brings the highest level of
performance to an elegant slim five-driver four-way tower configuration. Though
occupying little more than one square foot of floor space, the internally
powered 48″ Signature XD delivers tremendous clarity and impact with 650
watts of refined ICEpower® amplification.

The mastering grade speaker system articulates the treble
region with Legacy’s Dual AMT tweeter configuration. The air displacement and
acceleration of the 1” and 4” pleated diaphragms is four times greater than
conventional tweeters, thus providing greater air and detail. Vocals are
delivered by Legacy’s recently developed 7” graphene filled carbon fiber
midrange with a massive magnetic structure, computer optimized copper phase-
plug and shorting ring. The dual 10” woofers employ a rigid aluminum diaphragm
capable of reinforcing the lower vocal range and mid-bass, enriching baritones
and larger stringed instruments as only larger speakers could previously. The
powerful amplification assures bass weight and heft.

The Signature XD affords unusual flexibility in amplifier
configuration and room placement. The self-powered speaker system can be driven
full range with its pristine internal amplifier. The crossover network can be
divided with the flick of a switch allowing the upper section to be driven with
external amplification of the user’s choice. This feature accommodates the
invested tube and Class A aficionados.

The Signature XD system can be placed near the front wall
without concern due to its sealed configuration. The proprietary internal
dynamic damping circuitry and carefully implemented crossover points greatly
reduce colorations from early reflections. Even greater results can be achieved
by employing the Legacy Wavelet processor which also facilitates
bi-amplification.

Dual Air Motion Tweeter System

The ribbon drivers of the Legacy Dual Air Motion Tweeter
system are the very same used in the Legacy Focus SE (positioned at exactly the
same listener height as the Focus SE) and employ planar and folded diaphragms
suspended in high magnetic force field provided by neodymium. A natural
fullness in the treble is exhibited that reminds us why we love high-end audio
so much.

Signature XD additionally features silver HF wire on the
treble and Solen® capacitors in the high frequency section.

Dual 10″ Woofers

Signature XD employs dual 10” woofers, paired to reduce
distortion, while the sealed alignment couples to the floor boundary to achieve
highly controlled low frequency extension.

Signature XD has the ability to be placed very close to the
back wall thanks to its sealed box alignment. Taut bass lines emerge with solid
punch and no over-hang.

• Application
  Sealed enclosure, low sensitivity to room placement

• System
  Type 5 driver, 4 way

• Tweeter
  Dual Air Motion Tweeter System – 1” AMT super tweeter, silver HF wire

• Midrange
  Dual Air Motion Tweeter System – 4” AMT tweeter

• Midrange7”
  Graphene-filled carbon fiber cone with cast frame

• Subwoofer
  Dual 10” spun aluminum diaphragm, rubber surround, long throw suspension
  with case frame

• Low
  Frequency Alignment Sealed, dynamic damping

• Inputs
  Preamp level: XLR/RCA with adapter

• High
  Level 1pr of 5-way binding posts

• Internal
  Amplification 650 watts ICEpower® amplification

• Recommended
  Amplification 20-300 watts for upper section

• Freq.
  Response (Hz, +/-2dB) 22-30K

• Impedance
  4 Ohm

• Sensitivity
  92 dB (2.83V @ 1m)

• Crossover
  (Hz) 180, 2.8K, 8K

• Dimensions
  HxWxD (inches) 48 x 12 x 13.75

• Weight (each) 110 lbs each
