Description
The VXXT6R delivers powerful audio in a compact round design, ideal for outdoor, moisture-dense, or other extreme environments that demand performance. The IP66-rated, in-ceiling speaker features Sonance XPC (Extreme Post Capture) grille retention, and is available in round, micro trim or trimless bezel aesthetic to blend into any architectural design. Trimless grille and square grilles optional, sold separately.
Product Details
-
Brand SONANCEProduct Category Visual ExperienceType SpeakerSpeaker Shape RoundSpeaker Size 6″Color Brilliant White (Satin)Warranty LIMITED FIVE (5) YEARPower Handling 5 watts minimum; 125 watts maximumCut-Out Dimensions (Diameter) 8.25″ (209.55 mm)Dispersion Technology Sinusoidal Textured WaveguideFrequency Response (+/- 3dB)45Hz – 20kHz +/-3dBImpedance 8 ohms nominal; 6 ohms minimumInstallation LocationIn-CeilingIP Rating IP66Maximum Operating Temperature 194 F (89.9 C)Minimum Impedance 6 OhmsMinimum Operating Temperature -40 F (-39.96 C)Mounting Depth – Speaker Only 3.62″ (91.95 mm)Mounting Depth with Retrofit Enclosure 5.06″ (128.5mm)Nominal Impedance 8 OhmsProduct Depth 3.74″ (95.0 mm)Product Diameter 9.17″ (232.92 mm)Product Dimensions – Micro Trim Grille (WxH) 9.64″ (244.8mm)Product Dimensions – Square Micro Trim Grille (WxH) 9.64″ x 9.64″ (244.8mm x 244.8mm)Product Dimensions – Square Trimless Grille (WxH) 9.28″ x 9.28″ (235.6mm x 235.6mm)Product Dimensions – Trimless Grille (WxH) 9.28″ (235.6mm)Product Dimensions (Diameter x D) 9.17″ x 3.74″ (232.92 mm x 95.0 mm)Product Weight 10.8 lbs. (4.9 kg)Sensitivity 89dB (2.83V/1m)Shipping Dimensions WxHxD 11.37″ x 12.67″ x 11.8″ (288.8 mm x 321.82 mm x 299.72 mm)Shipping Weight 13.78 lbs. (6.25 kg)Speaker Tweeter 1.0″ (25mm) waterproof cloth dome, Ferrofluid-cooled, acoustic back chamberSpeaker Woofer 6.5″ (165mm) polypropylene cone, Santoprene surroundSpecialty Application Extreme
